[EU Direct] GELEIPU 12V 12.8V 200Ah LiFePO4 Battery, 2560Wh Rechargeable Lithium Battery Built-in 100A BMS, Perfect for Trolling Motor Solar System
[EU Direct] GELEIPU 12V 12.8V 200Ah LiFePO4 Battery, 2560Wh Rechargeable Lithium Battery Built-in 100A BMS, Perfect for Trolling Motor Solar System
In stock
Couldn't load pickup availability
Specifications:
Brand |
GELEIPU |
Cell |
Prismatic LiFePO4 Battery |
Nominal Capacity |
200Ah |
nominal Voltage |
12.8V |
RecommendedCharging Current |
20A |
BMS |
100A |
Energy |
2560Wh |
InternalResistance |
≤40mΩ |
Max. Continuous Charging Current (BMS) |
100A |
Max.Continuous Discharge Current (BMS) |
100A |
Max. Discharge Current 5 Seconds |
280A |
Housing |
ABS (Flame Retardant Plastic) |
Protection Class |
IP65 |
Temperature Range |
-20°C to 50°C |
Weight |
47.4lbs / 21.5kg |
Dimension(L*W*H) |
21*9.4*8.5 inches |
Features:
1.[100% DOD] 12V 200Ah lithium batteries can reach a depth of discharge of 100%, while lead-acid batteries can only reach 50%. Based on the depth of discharge and cycle life, 1 Geleipu 12V 200Ah = 4 12V 100Ah lead-acid batteries, and the Geleipu 12V LiFePO4 battery supports 100% DOD (4000+ cycles @ 100% DOD, 6000+ cycles @ 80% DOD, 15000+ cycles @ 60% DOD), while the AGM battery supports 50% DOD.
2.[100A BMS Protection] The Geleipu 12.8V 200Ah battery is equipped with an inbuilt 100A BMS that provides protection against overcharge, over discharge, over current, short circuit and over temperature. Whether used indoors or outdoors, it guarantees safety and protection.
3.[10-Years Lifespan] Geleipu is equipped with high-quality LiFePO4 batteries, which ensure excellent quality, higher energy density, stable performance and higher output. Geleipu's LiFePO4 batteries are guaranteed to provide 4000+ cycles and a lifespan of 10 years.
4.[Expandable for wide applications] The Geleipu 12.8V 200Ah battery supports a maximum 4P4S connection to reach up to 40.96kWh (40.96kW), for 40.96kWh energy and max. 40.96kW load power. The applicable scenarios are wider.
5.[Light weight | Small size] The Geleipu 12.8V 200Ah lithium battery weighs only 21.5kg, less than half the weight of a lead-acid battery with the same energy. It is more convenient to transport and faster to charge, making it suitable for outdoor and indoor use.
6.[Application] The Geleipu 12.8V 200Ah LiFePO4 battery is recommended for solar energy storage, trolling motors with 30~70lbs thrust, RV backup batteries, off-grid systems and home battery packs.
This battery is not suitable for use as a starter battery or golf cart battery.
Powerful BMS protection measures
1. Protection against overcharging
2. Overcurrent protection
3. Protection against over-discharge
4. Protection against short circuit
5. Shutdown at high temperature
Package includes:
1 x Energy Storage Battery
1 x User Manual
